DVB-T/T2(HEVC 10 bit)/C/J.83B/ISDB-T and DVB-S/S2 signal meter
AS07STCA-4K with spectrum analyzer and calibration certificate
The AS07STCA-4K certified signal meter can measure DVB-S/DVB-S2 (4K) satellite signal, DVB-T/T2 (4K) terrestrial TV signal in HEVC 10 Bit compression and C/J.83B/ISDB-T cable signal.
• Measurement of DVB-T/T2/C/J.83B/ISDB-T and DVB-S/S2 signals
• Support for DVB-T2 with H.265/HEVC 10 bit
• Built-in video decoder: MPEG-2/H.264/HEVC(H.265) 4K
• Certified calibration
• Menu in Polish, English, Italian, Spanish, Portuguese, Czech, German, Arabic
• Measurement of all necessary signal parameters such as signal level expressed in dBμV, MER, Link Margin, CBER, VBER
• USB connector (possibility to take a screenshot of current signal measurement, export measurements to .csv file)
• RF signal measurement in the range of 20…100 dBμV
• View of the received channel on the touch screen TFT-LCD display size 7″ with high resolution 4K
• DiSEqC support: 1.0, 1.1,1.2, 0/22 kHz Tone, Unicable (dSCR), Wideband
• Real-time signal spectrum analyzer for detecting interference from LTE signals
• Constellation display
• Large Li-On 7.4 V/7000 mAh battery – enough for about 3-4 h of continuous operation
• Efficient and easy-to-use user interface.
Details
Professional signal meter AS07STCA-4K
R10206 allows to measure DVB-S/DVB-S2 (4K) satellite signal, DVB-T/T2 (4K) terrestrial TV signal in HEVC 10 Bit compression and C/J.83B/ISDB-T cable signal. An unquestionable advantage of the device is its clear and easy-to-use user interface which makes it easy to work on a high-resolution 7″ TFT-LCD touchscreen display. The AS07STCA-4K meter allows you to measure such parameters as: signal level expressed in dBμV (measurement range 20…100 dBμV), MER, Link Margin, CBER, VBER which allows you to set up any terrestrial and satellite TV antenna, tune filters, select amplifiers, etc. The meter has a built-in tuner for continuous viewing of the set channel in 4K resolution. The spectrum distribution analyzer especially for terrestrial TV allows visualization of strong interfering LTE signals (a function that allows real-time comparison), which can negatively affect the quality of the DVB-T2 signal, causing interference and interfering with proper reception of digital terrestrial TV. In addition, the HDMI output allows you to display the image on another screen (for example, a TV) via HDMI cable. A car charger is included The BNC socket allows you to view images from AHD-TVI-CVI-PAL CCTV cameras. An unquestionable advantage of the meter is the preview of the signal spectrum in the 5G (700 MHz), 4G (800 MHz), GSM (900 MHz, 1800 MHz), 3G UMTS (2100 MHz) bands.
Each AS07STCA-4K meter comes with a certificate of calibration which proves top quality workmanship and ensures the reliability of the measurements made in TV systems.
